Main Features:

>> Accuracy and Linearity Error Levels: Level 0.2 and Level 0.5

>> Standard Signal Inputs: 4-20mA, 0-5V, 0-10V, etc.

>> Current Signal Outputs: 0-8A, 0-10A, etc.

>> Voltage Signal Outputs: 0~1V (max 10A), 0~10V, 0-24V (max 10A), etc.

>> Signal Input/Output Isolation: 3000VDC

>> Auxiliary Power Supply: 24V DC Single Supply

>> Auxiliary Power Supply and Output Signal Not Isolated

>> Screw-Mounted Installation, Plug-in Terminal Blocks

>> Dimensions: 120 x 105 x 29mm

>> Industrial Temperature Range: -45 ~ +85 ℃

 Applications:

>> Industrial Field Signal Isolation and Amplification

>> Current Signal Amplification or Voltage Signal Drive Capability Enhancement

>> Solenoid Valve, Proportional Valve Linear Driver

>> Solenoid Switch Linear Controller

>> Solenoid Drive Coil or High-Power Load

>> Ground Interference Suppression

Product selection table:

Note: Please inform us of the size of the output load resistor when placing your order.


Selection examples: Example 1: Input signal: 0-10V, power supply: 24V, output signal: 0-10A, load resistance: 2 ohms, model: DIN11G IAP V2-P1-AzNote: Please inform us of the size of the output load resistor when placing your order.

Note: Please inform us of the size of the output load resistor when placing your order.


Example 3: Input signal: 0-3V, power supply: 24V, output signal: 0-24V, load: 10A, model: DIN11G IAP Vz-P1-Vz

Product manual：https://www.wayjun.cn/d/
